24V 1-Channel 433M 2-Button White Remote Control Switch + Receiver Module

- Specification: - Material: FR4 glass plate - Size: Approx. 55x35x22mm / 2.17x1.38x0.87inch - Receiving distance: between 15-100 meters (through the wall) - Working mode: self-loing, jogging, interloing three working modules - Scope of application: water pump, light bar, lamp, home appliances, machinery and equipment, mechanical switch, roll gate, shutter curtain, etc. - Work instructions: D2 (power indicator), D4 (relay switch indicator), D3 (learning indicator) - Output mode: output is passive output, the module is mainly used as a switch; (for the often open), COM (for the common), CB (for the regular closure) (Note: CB and COM normal state is connected, Switch used when the CB is usually not used, only and COM two interfaces) - First, learning methods: - 1, power, press and hold the module above the learning button, learning light D3 flash 1, release the button, and then press the need to learn the remote control button (such as A key), learning light flash 3 to prove this button to learn success - 2, power, press and hold the module above the learning button, learning light D3 flash 2, release the button, and then press the need to learn the remote control button (such as B key), learning light flash 3 to prove that the other button Learning success - Second, the wireless function to clear the method: - After power, has been holding down the learning button, learning light D3 first flash 2, and then quily flash 3, said the module cleared successfully - Third, self-loing, jogging, interloing operation - Interlo: power state, press and hold the learning button after power, learning light D3 flash 2, the release button, this time set to interlo output. (This mode is used for two keys of the remote control operation, A button to open, B button off) - Self-loing: power state, press the learning button after power, learning light D3 flash 3, the release button, this time set to self-loing lo output. (For single-button control) - Jogging: power off state, press and hold the learning button after power, learning light D3 flash 4, the release button, this time set to jog output. (For single-button control) - Paage Includes: - 1x Wireless Switch Module - 1x Remote controller Giá sản phẩm trên Tiki đã bao gồm thuế theo luật hiện hành. Bên cạnh đó, tuỳ vào loại sản phẩm, hình thức và địa chỉ giao hàng mà có thể phát sinh thêm chi phí khác như phí vận chuyển, phụ phí hàng cồng kềnh, thuế nhập khẩu (đối với đơn hàng giao từ nước ngoài có giá trị trên 1 triệu đồng).....
