Màn hình WECON LEVI2043T 4.3INCH

◇ Display size: 4.3 inch ◇ Resolution: 480×272 TFT LCD 65536 colors ◇ Interface: Support RS232/RS485/RS422 ◇ Storage: Support Date Storage, U Disk ◇ Kích thước hiển thị ◇ Độ phân giải màn hình: ◇ Giao diện: Support RS232/RS485/RS422 ◇ Lưu trữ: 128M FLASH, 64M DDRAM II General Thông tin chung: _Colors 65536 colors _Brightness 450cd/m2 _Backlight Type LED _Touch Screen High procision four-wire resistive _Backlight Life Time 50000 hours _CPU 32-bits 300MHz RISC _Storage 128M FLASH + 64M DDRAM _RTC 256KB _Printer Port Serial port Printer _USB Port USB host + USB Client _SD card _COM1 RS422/RS485 _COM2 RS232 _Power <5w _Power Supply DC 24V ( 12~28V DC ) _Allowed Power Fail <5ms _Insulation Resistance >20MΩ 500V DC _Withstand Voltage 500V AC < 1 minute Dimension Kích thước _Shell ABS,Black _Dimension (mm) 141.4W*85.4H*38.9D _Mounting size (mm) 131.0W*79.0H _Net/Gross (KG) 0.23/0.39 Operate Environment +Temperature: _Working Temperature : -10~60℃ ; _Storage Temperature : -20~70℃ _Humidity Working Humdity : 10~90% RH ; _Storage Humidity : 10~90%RH _Seismic Resistance 10~25 Hz ( X,Y,Z direction 2G/30 minutes) (Chống sốc) _Cooling Air cooling _Protection IP65 ( Front panel ) _CE Certification: CE marked
